NSK Angular Contact Ball Bearings 7000 – High-Speed Machine Tool Bearings

NSK Angular Contact Ball Bearings 7000 – High-Speed Machine Tool Bearings

The NSK 7000 Angular Contact Ball Bearings are designed for high-speed precision applications, particularly in machine tools. With their specialized contact angles (15°, 30°, 40°, and special 25° versions), these bearings can handle significant one-way axial loads, with a greater contact angle offering a higher load capacity. Constructed with high-quality steel balls and available in multiple configurations, they ensure efficient and reliable performance in demanding industrial environments.

Specifications:

• Bearing Type: Angular Contact Ball Bearings
• Model: 7000 Series
• Contact Angles:
  • 15° (C)
  • 30° (A)
  • 40° (B)
  • Special 25° (A5)
• Material: Steel balls with steel, brass, or engineering plastic retainers
• Combinations:
  • SU: Single bearing
  • DU: Free combination (2 column)
  • DB: Back-to-back combination
  • DF: Face-to-face combination
  • DT: Tandem combination
  • DBD, DFD, DTD: 3-column combinations
  • DBB, DFF, DBT, DFT, DTT: 4-column combinations
• Preload:
  • C10: Standard preloaded
  • C9: Lightly preloaded (low torque)
• Precision Grades:
  • PN7A: Standard precision (ISO 4 class)
  • PN7B: Special control precision for inner and outer diameter (ISO 4 grade)

Features:

1. High Load Capacity: Capable of bearing radial-axial combined loads or pure thrust loads, offering higher load capacity than deep groove ball bearings of similar dimensions.
2. Low Friction & High Speed: Engineered for low operating friction and high-speed performance.
3. Versatile Use: Widely used in mechanical industries, including metallurgical machinery, mining, paper-making machinery, and other industrial applications.
4. Structural Variety: Available in single-row, matched, double-row, and four-point contact designs.

Applications: Ideal for ball screw support in machine tool applications, various machinery such as metallurgical, mining, paper-making, and more.
