QKG Precision Grinding Vise 1.5" 2" 2.5" | Mini CNC Milling Toolmaker Vise HRC58-62 High Accuracy
QKG Precision Grinding Vise 1.5" 2" 2.5" – Toolmaker CNC Milling and Surface Grinder Vise HRC58-62
The QKG precision grinding vise is a professional toolmaker vise designed for high-precision machining applications including surface grinding, CNC milling, EDM, and wire cutting. Manufactured from hardened alloy carbon tool steel (20rMnTi) with hardness rated at HRC58-62, it ensures maximum durability, rigidity, and wear resistance.
With ultra-high positioning accuracy of 0.005mm (0.0002") and precision-ground surfaces, this vise provides excellent parallelism and repeatable machining performance. The V-groove movable jaw allows secure clamping of round, square, and irregular workpieces.
Its compact design makes it ideal for small precision work, toolmaking, inspection, and CNC machining environments requiring maximum accuracy and stability.
Perfect for CNC machines, surface grinders, milling machines, and precision workshops, this vise delivers reliable performance and professional machining results.
Key Features and Benefits
Precision up to 0.005mm (0.0002") for reliable machining.
Alloy carbon tool steel hardened to HRC58-62 for durability.
Ensures flatness, parallelism, and high machining accuracy.
Secure clamping of round and irregular workpieces.
Ideal for small precision machining applications.
Long service life and wear resistance.
Applications
- Surface grinding machines
- CNC milling machines
- Wire EDM machines
- Precision toolmaking
- Machining workshops
- Inspection and precision work
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | QKG Precision Grinding Vise |
| Jaw Width Options | 38 mm (1.5") 50 mm (2") 63 mm (2.5") |
| Material | Alloy Carbon Tool Steel (20rMnTi) |
| Hardness | HRC58-62 |
| Accuracy | 0.005mm (0.0002") |
| Drive Mode | Manual |
| Certification | CE |
| Applications | Surface grinding, CNC milling, EDM, toolmaking |
Dimensions and Size Chart
| Model | Jaw Width | Height | Max Opening | Length | Weight |
|---|---|---|---|---|---|
| QKG38 | 38 mm (1.5") | 40 mm (1.57") | 44 mm (1.73") | 105 mm (4.13") | 0.9 kg (1.98 lbs) |
| QKG50 | 50 mm (2") | 50 mm (1.97") | 65 mm (2.56") | 140 mm (5.51") | 1.6 kg (3.53 lbs) |
| QKG63 | 63 mm (2.5") | 65 mm (2.56") | 85 mm (3.35") | 175 mm (6.89") | 3 kg (6.61 lbs) |
